Single-Side
Fixed with connectors
NO LED
Each bar length can be customized
6063-T5 Aluminum
0.46KG/M
The LC-SR-25B is a 25mm deep single-sided SEG aluminum profile featuring an optimized cross-section that reduces overall weight while maintaining reliable performance for non-illuminated displays. Compared to the heavier 25A variant, the 25B uses material more efficiently to deliver a lighter frame that is especially well-suited for portable exhibition kits, pop-up displays and temporary event installations where ease of transport and assembly are priorities. Crafted from 6063-T5 aluminum alloy, it still delivers excellent straightness and structural integrity for wall-mounted graphics up to medium-large sizes.
With only 25 mm of build-up, LC-SR-25B is specified where the frame has to disappear — meeting-room graphics, showroom captions and corridor signage that sit flat against plaster or laminate. One face, one graphic: there is no second panel, diffuser or light cavity, which is why this profile is the cheapest way to hold a silicone-edge fabric taut on a flat wall.
The section is drawn in 6063-T5 aluminum, 0.46 kg per metre; the visible face is flat with a satin finish, and the groove holds a 2–3 mm silicone edge without visible seams at the corners. Because there is no cavity, the profile also suits double-mounting on a partition where access from behind is impossible.
Bars ship at 3.5 m, 5 m or 6 m (custom lengths on request), cut to your drawing with a ±1 mm length tolerance and deburred ends; longer runs are packed as matched bars with the corner set bagged alongside. Stock sections are quoted within 24 hours; custom colours and cut lists run 15–25 days, and a sample length can be sent before you commit to the full frame.
LC-SR-25B is a single-sided frame, at 25 mm depth, 0.46 kg per metre, in 6063-T5 aluminum; bars come at 3.5 m, 5 m or 6 m (custom lengths on request), packed in plastic/kraft paper.
Q: Does LC-SR-25B take LED lighting?
A: No — LC-SR-25B is a non-illuminated SEG frame. For a lit panel, step up to a double-sided profile with an LED row and diffuser.
Q: What lengths and colours can I order?
A: 3.5 m, 5 m or 6 m (custom lengths on request), cut to your list; colours are silver, black, white or a custom colour.
Q: How fast is a quote and a sample?
A: Quote within 24 hours of a drawing or size list; stock ships in 3–5 days, custom coating 15–25 days, and sample pieces go out before bulk.
| Item number | LC-SR-25B |
|---|---|
| Depth | 25MM |
| Frame type | Single-sided frame |
| Mounting | Mounted on the wall |
| Material | 6063-T5 Aluminum |
| Colors | SILVER/BLACK/WHITE/Color of your choice |
| Weight | 0.46KG/M |
| LED | NO LED |
| Bar length | 3.5M/5M/6M/Each bar length can be customized |
| Package | Plastic/kraft paper, different packaging will bring price changes |
